Draper 3/8 Air Ratchet Wrench Compact Stubby Yoke 85Nm Pneumatic Torque Aluminium Housing Red

Description

Draper 3/8 Air Ratchet Wrench Compact Stubby Yoke 85Nm Pneumatic Torque Aluminium Housing Red

• Lightweight aluminium housing with ergonomic soft-grip handle for comfortable prolonged use
• Compact stubby-yoke design with 3/8 square drive for automotive maintenance and repair applications
• Pneumatic operation at 90 psi (6.2 bar), with 4-speed rear regulator and 85 Nm (60 ft-lb) ultimate torque
• 360° rotating air inlet helps reduce airline kinking; suitable for radiators, spark plugs, air-conditioning and water-pump work

The Draper 3/8 Air Ratchet is a compact pneumatic ratchet wrench designed for automotive repair, maintenance and workshop applications where access and manoeuvrability are important. Its stubby yoke and compact construction make it suitable for working in confined areas around vehicle components.

The tool features a lightweight aluminium housing combined with an ergonomic soft-grip handle, helping provide a comfortable and secure hold during extended periods of use. The 3/8 square drive is suitable for compatible sockets used for general automotive fastening and removal tasks.

A four-speed rear regulator allows the user to adjust the tool’s operating speed, while the pneumatic mechanism provides a free speed of up to 160 rpm and an ultimate torque of 85 Nm (60 ft-lb). The twin ratchet pawl design is intended to provide positive ratcheting action during use.

The air system incorporates a 1/4 BSP airline connector and a 360° rotating air inlet, helping reduce strain and prevent the airline from kinking as the tool is repositioned. A middle exhaust arrangement and turnable exhaust deflector help direct discharged air away from the working area.

With an operating pressure of 90 psi (6.2 bar) and average air consumption of approximately 4 cfm (113 L/min), this Draper pneumatic air ratchet is suited to workshop and automotive applications including removing or replacing radiators, spark plugs, air-conditioning components and water pumps.

Product Benefits

• Compact design provides improved access in restricted working areas
• Pneumatic operation reduces manual effort during repetitive fastening and removal
• Adjustable four-speed control and rotating air connection provide greater control and manoeuvrability

Features & Specifications

• Brand: Draper
• Product type: Pneumatic air ratchet
• Colour: Red
• Square drive: 3/8
• Ultimate torque: 85 Nm (60 ft-lb)
• Free speed: 160 rpm
• Operating air pressure: 90 psi (6.2 bar)
• Average air consumption: 4 cfm (113 L/min)
• Minimum hose size: 3/8 (10 mm)
• Air inlet: 1/4 BSP
• Operation mode: Pneumatic
• Speed control: 4-speed rear regulator
• Drive mechanism: Twin ratchet pawls
• Exhaust: Middle exhaust with turnable exhaust deflector
• Air inlet: 360° rotating
• Vibration level: 4.35 m/s²
• Item package quantity: 1
• Material: Aluminium housing with soft-grip handle

Measurements

• Tool length: 300 mm
• Square drive: 3/8

Materials & Care Instructions

• Housing: Lightweight aluminium
• Handle: Ergonomic soft-grip material
• Keep the tool clean and dry after use.
• Disconnect the air supply before cleaning, maintenance or changing sockets.
• Use a suitable compressed-air supply regulated to the specified 90 psi (6.2 bar) operating pressure.
• Maintain the pneumatic mechanism
• Store in a dry environment away from excessive moisture and contamination.

Included Components

• 1 × Draper 3/8 pneumatic air ratchet
